X5070 Long 4-Flute 30° Helix Ball Nose End Mill – G8D62 1

X5070 Long 4-Flute 30° Helix Ball Nose End Mill – G8D62 2

X5070 Long 4-Flute 30° Helix Ball Nose End Mill – G8D62

Price range: $33.35 through $95.79

Mill Diameter (mm)

Ball Nose Radius (mm)

Clear

Quantity

SKU: N/A Category: Milling Machines Brand: Excision Pty Ltd

Description

The YG-1 G8D62 X5070 Blue cutter is a 4-flute 30° helix long ball end. Special centre match ball nose geometry drives highest cutting performance in 3D machining. Nanograin substrate and silicone based coating enable dry machining to 1400°c in steels to HRc70. Diameters 3mm to 20mm with ultra low cut depth and exceptionally high feed rates.

Specifications

Flutes	4
Helix Angle	30°
Cutting Edge Shape	Ball Nose
Size Min	R1.5
Size Max	R10.0
Length	Center Match
Coating	Blue Coating

Explore more from our collection.

Additional information

Mill Diameter (mm)	3.0, 4.0, 5.0, 6.0, 8.0, 10.0, 12.0, 16.0, 20.0
Ball Nose Radius (mm)	R1.5, R2.0, R2.5, R3.0, R4.0, R5.0, R6.0, R8.0, R10.0
